• Jetson Orin Nano™ 4GB

- CPU: 6-core ArmCortex-A78AE v8.2 64-bit, 1.5MB L2 + 4MB L3

- GPU: 512-core NVIDIAAmpere architecture with 16 Tensor Cores

- Memory: 4GB 64-bit LPDDR5 51 GB/s

- AI performance: 34 INT8 Sparse TOPS, Super Mode

• Jetson Orin Nano™ 8GB

- CPU: 6-core ArmCortex-A78AE v8.2 64-bit, 1.5MB L2 + 4MB L3

- GPU: 1024-core NVIDIAAmpere architecture with 32 Tensor Cores

- Memory: 8GB 128-bit LPDDR5 102 GB/s

- AI performance: 67 INT8 Sparse TOPS, Super Mode

• OpenGL 4.6, OpenGL ES 3.2, CUDA10 and Vulkan 1.1

• 260-pin SO-DIMM form factor compatible with Orin™ NX

• NVIDIA JetPack™ 6.2

• 1 x Full-size Mini PCIe slot

- Support a Wi-Fi/BT module

• 1 x M.2 Key B 3042/3052

- Support a 5G/LTE module

• 1 x HDD LED

• 1 x COM port (COM 1), supports RS-232/422/485

• 1 x COM port (COM 2), supports RS-232 (only Tx/Rx)

• 1 x Micro-USB OTG

• 3 x Antenna hole

• 1 x Full-size Mini PCIe slot, supports Wi-Fi / BT Module

• 1 x M.2 3042/3052 Key B, supports 5G / LTE Module

• 1 x 3-pin Phoenix terminal block

• 2 x USB 2.0, Type-A

• 2 x USB 3.2 Gen 1x1, Type-A

• 4 x 1GbE RJ45 port (optional PoE)

- Support IEEE 802.3af, Class 3, 15W

• 1 x HDMI2.0, up to 4096 x 2160@60Hz

• 1 x Power button

• 1 x HDD LED

• 1 x COM 1, supports RS232/422/485

• 1 x COM 2, supports RS232 (only TX/RX)

• 3 x Antenna hole

• 1 x M.2 2280 Key M SSD (PCIe Gen 3 x 4)

• DC 24V input, ± 20%

• Operating temperature

- Ambient with air flow : -20°C to 60°C

- Storage temperature : -20°C to 80°C

• Relative humidity : 10%~95% (non-condensing)

• Vibration protection

- Random : 2Grms @ 5 ~ 500Hz, IE60068-2-64

- Sinusoidal : 2G @ 5 ~ 500Hz, IEC60068-2-6

• Dimension : 240mm (W) x 154mm (D) x 54mm (H)

• Net Weight : 2.03 kg

• Gross weight : 2.42kg, 1 unit per carton

• NVIDIA Jetpack™ 6.2, supports Super Mode

• CE (EMC EN 55032 + EN 55024)

• FCC Class A (EMI Part 15B)
